Assessment of the content of toxic and essential elements in the urine of children residing in rural and industrial regions in Western Urals

Cover Page

Cite item

Full Text

Abstract

Introduction. The element composition of urine is relevant and demanded index in biomedical, biomonitoring studies to assess the level of contamination of biological media and public health risks.

Material and methods. The content of 12 elements (V, Cr, Mn, Ni, Cu, Zn, As, Se, Sr, Cd, Tl, Pb) in urine of unexposed children (n = 100 and n = 57, respectively, average age < 6 years) residing in the rural and industrial region of the Western Urals was determined by ICP-MS using Agilent 7500cx inductively coupled plasma quadrupole mass spectrometer (Agilent Technologies, USA) with an octopole reaction / collision cell (ORS). The measurement was carried out according to Methodical Guidelines 4.1. 3230-14 (FR.1.31.2014.17064) developed by the authors. Urine samples were directly analyzed after 1/10 dilution (V / V) with 1% nitric acid solution. The validity of the results was confirmed by analysis of standard urine samples SERONORMTM urine (Norway). The results were presented as basic statistical indices: minimum and maximum values, arithmetic mean (AM), geometric mean (GM), 5th, 50th, 95th percentiles, and were interpreted in accordance with current international requirements.

Results. In the unexposed group of children the arithmetic mean (AM) for vanadium is 0.68 μ/l; chromium - 1.91 μg/l; manganese 0.96 - μg/l; nickel - 1.84 μg/l; copper - 13.28 μg/l; zinc - 270.56 μg/l; arsenic - 18.- 99 μg/l; selenium - 22.55 μg/l; strontium - 239.09 μg/l; cadmium - 0.12 μg/l; thallium - 0.16 μg/l; lead - 0.83 μg/l. The arithmetic mean in the group of children of the industrial territory for vanadium is - 0.72 μg/l; chromium - 2.13 μg/l; manganese - 1.11 μg/l; nickel - 2.76 μg/l; copper - 26.67 μg/l; zinc - 482.1 μg/l; arsenic - 10.09 μg/l; selenium - 32.84 μg/l; strontium - 1275.35 μg/l; cadmium - 0.122 μg/l; thallium - 0.16 μg/l; lead - 2.16 μg/l. Evaluation of the results of the study showed AM excess of nickel, copper, zinc, strontium and lead.

Conclusion. The paper presents regional features of the urine elemental composition in children who permanently reside in Western Urals’ rural and industrial areas. The study results based on the 95 percentile (P95) can be used as approximate reference data as a basis for assessing the risk associated with exposure to metals. The comparative evaluation of the obtained results with the reference concentrations used in Europe, the USA and Canada for national human biomonitoring programs was carried out.

About the authors

Tatyana S. Ulanova

Federal Scientific Center for Medical and Preventive Health Risk Management Technologies

Author for correspondence.
Email: ulanova@fcrisk.ru
ORCID iD: 0000-0002-9238-5598

MD, Ph.D. DSci., Head of the Department of Chemical and Analytical Research Methods Federal Scientific Center for Medical and Preventive Health Risk Management Technologies, Perm, 614045,Russian Federation.

e-mail: ulanova@fcrisk.ru

Russian Federation

Nina V. Zaitseva

Federal Scientific Center for Medical and Preventive Health Risk Management Technologies; E.A.Wagner Perm State Medical University

Email: noemail@neicon.ru
ORCID iD: 0000-0003-2356-1145
Russian Federation

Galina A. Veikhman

Perm State Pharmaceutical Academy

Email: noemail@neicon.ru
ORCID iD: 0000-0002-8490-7624
Russian Federation

Elena V. Stenno

Federal Scientific Center for Medical and Preventive Health Risk Management Technologies

Email: noemail@neicon.ru
ORCID iD: 0000-0001-5772-2379
Russian Federation

Anna V. Nedoshitova

Federal Scientific Center for Medical and Preventive Health Risk Management Technologies

Email: noemail@neicon.ru
ORCID iD: 0000-0001-6514-7239
Russian Federation

Marina V. Volkova

Federal Scientific Center for Medical and Preventive Health Risk Management Technologies

Email: noemail@neicon.ru
ORCID iD: 0000-0002-0600-4075
Russian Federation

References

  1. Bevan R., Jones K, Cocker J., Assem F.L., Levy L.S. Reference ranges for key biomarkers of chemical exposure within the UK population. Int. J. Hyg. Environ. Health. 2012; 216(2): 170–4. https://doi.org/10.1016/j.ijheh.2012.03.005
  2. CDC. Fourth National Report on Human Exposure to Environmental Chemicals. Atlanta, Georgia; 2005.
  3. WHO. Human biomonitoring: facts and figures. Copenhagen; 2015.
  4. Egorov A.I., Il’chenko I.N., Lyapunov S.M., Marochkina E.B., Okina O.I., Ermolaev B.V., et al. Application of a standardized human biomonitoring methodology to assess prenatal exposure to mercury. Gigiena i Sanitaria (Hygiene and Sanitation, Russian journal). 2014; 93(5): 10–8. (in Russian)
  5. Ivanenko N.B., Ganeev A.A., Solov’ev N.D., Moskvin L.N. Determination of trace elements in biological fluids. Zhurnal analiticheskoy khimii. 2011; 66(9): 784–99.
  6. Hays S.M., Aylward L.L., Lakind J.S., Bartels M.J., Barton H.A., Boogaard P.J., et al. Biomonitoring equivalents expert workshop. Guidelines for the derivation of biomonitoring equivalents: report from the biomonitoring equivalents expert workshop. Regul. Toxicol. Pharmacol. 2008; 51(3 Suppl.): S4–15. https://doi.org/10.1016/j.yrtph.2008.05.004
  7. Hays S.M., Nordberg M., Yager J.W., Aylward L.L. Biomonitoring Equivalents (BE) dossier for cadmium (Cd) (CAS No. 74440-43-9). Regul. Toxicol. Pharmacol. 2008; 51(3 Suppl.): S49–S56. https://doi.org/10.1016/j.yrtph.2008.05.008
  8. Angerer J., Ewers U., Wilhelm M. Human biomonitoring: state of the art. Int. J. Hyg. Environ. Health. 2007; 210(3-4): 201–28. https://doi.org/10.1016/j.ijheh.2007.01.024
  9. Schulz C., Wilhelm M., Heudorf U., Kolossa-Gehring M. Update of the reference and HBM values derived by the German Human Biomonitoring Commission. Int. J. Hyg. Environ. Health. 2011; 215(1): 26–35. https://doi.org/10.1016/j.ijheh.2011.06.007
  10. Ewers U., Krause C., Schulz C., Wilhelm M. Reference values and human biological monitoring values for environmental toxins. Report on the work and recommendations of the Commission on Human Biological Monitoring of the German Federal Environmental Agency. Int. Arch. Occup. Environ. Health. 1999; 72(4): 255–60. https://doi.org/10.1007/s004200050369
  11. Saravanabhavan G., Werry K., Walker M., Haines D., Malowany M., Khoury C. Human biomonitoring reference values for metals and trace elements in blood and urine derived from the Canadian Health Measures Survey 2007–2013. Int. J. Hyg. Environ. Health. 2017; 220(2 Pt. A): 189–200. https://doi.org/10.1016/j.ijheh.2016.10.006
  12. Gileva O.V., Ulanova T.S., Veykhman G.A., Nedoshitova A.V., Stenno E.V. Methodical assurance of the assessment of toxic and essential elements in human biological matrices. Gigiena i Sanitaria (Hygiene and Sanitation, Russian journal). 2016; 95(1): 116–21. https://doi.org/10.18821/00169900-2016-95-1-116-121 (in Russian)
  13. Ulanova T.S., Nurislamova T.V., Karnazhitskaya T.D., Gileva O.V. Methodical peculiarities and guidelines for the determination of chemical compounds and elements in the biological matrices. Gigiena i Sanitaria (Hygiene and Sanitation, Russian journal). 2016; 95(1): 112–6. https://doi.org/10.18821/0016-9900-2016-95-1-112-116 (in Russian)
  14. Tietz Clinical Guide to Laboratory Tests. St. Louis: W.B. Saunders Company; 2006.
  15. ALS Scandinavia. Reference data. Biomonitoring. Trace Elements in human biological material; 2014. Available at: https://www.alsglobal.se/media-se/pdf/reference_data_biomonitoring_120710.pdf
  16. Associated Regional & University Pathologists. ARUP User Guide. Salt Lake City; 2004-2005.
  17. Kaletina N.I. Toxicological Chemistry. Metabolism and Analysis of Toxicants [Toksikologicheskaya khimiya. Metabolizm i analiz toksikantov]. Moscow: GEOTAR-Media; 2008. (in Russian)
  18. Report on Human Biomonitoring of Environmental Chemicals in Canada. Results of the Canadian Health Measures Survey Cycle 1 (2007-2009; 2010). Available at: https://www.canada.ca/content/dam/hc-sc/migration/hc-sc/ewh-semt/alt_formats/hecs-sesc/pdf/pubs/contaminants/chms-ecms/report-rapport-eng.pdf
  19. NHANES, Centers for Disease Control and Prevention. National Health and Nutrition Examination Survey. Fourth National Exposure Report, Updated Tables; 2017. Available at: https://www.cdc.gov/biomonitoring/pdf/FourthReport_UpdatedTables_Volume1_Jan2017.pdf
  20. Veykhman G.A., Gileva O.V., Stenno E.V., Ulanova T.S. Determination of toxic and essential elements in urine by inductively coupled plasma-mass spectrometry. Sovremennye tekhnologii v meditsine. 2016; 8(3): 120–5. https://doi.org/10.17691/stm2016.8.3.14 (in Russian)
  21. Heitland P., Köster H.D. Biomonitoring of 30 trace elements in urine of children and adults by ICP-MS. Clin. Chim. Acta. 2006; 365(1-2): 310–8. https://doi.org/10.1016/j.cca.2005.09.013
  22. Roca M., Sanchez A., Perez R. et al. Biomonitoring of 20 elements in urine of children. Levels and predictors of exposure. Chemospher. 2016; 144: 1698-1705.
  23. Alimonti A., Bocca B., Mannella E., Petrucci F., Zennaro F., Cotichini R., et al. Assessment of reference values for selected elements in a healthy urban population. Ann. Ist. Super Sanita. 2005; 41(2): 181–7.
  24. Società Italiana Valori di Riferimento (SIVR). 4° Lista dei Valori di Riferimento per Elementi, Composti Organici e Loro Metaboliti Edizione 2011; SIVR: Siena, Italy, 2011. www.valoridiriferimento.it
  25. Kolossa-Gehring M., Becker K., Conrad A., Schröter-Kermani C., Schulz C., Seiwert M. Environmental surveys, specimen bank and health related environmental monitoring in Germany. Int. J. Hyg. Environ. Health. 2012; 215(2): 120–6. https://doi.org/10.1016/j.ijheh.2011.10.013
